Technical details
Classification
Brand
Samsung
Clasification
EHS
Category
Mono
Type
Outdoor
Accessories
Space Heating Pump Included
No
Central Heating controller
No
Efficiency
SEER
0.0
SCOP
4.8
Noise rating
Sound (power) (dB(A))
60dB(A)
Sound (pressure) (dB(A))
47dB(A)
Output power
Cooling kW
12.5kW
Heating kW
14.0kW
UK Cooling kW
0.0kW
UK Heating kW
0.0kW
Sensible UK Cooling kW
0.0kW
Maximum Flow Temperature (°c)
70°c
Maximum Hot Water Temperature (°c)
70°c
Power supply
Power source
Three phase
Fuse Rating (Amps)
17.7Amps
Running Current (Amps)
5.56Amps
Product features
Refrigerant
R32
Colour
Shadow Grey
BMS Ready
Yes
Weights & dimensions
Width (mm)
1270mm
Depth (mm)
530mm
Height (mm)
1018mm
Pipe size (Liquid (mm))
28.0mm
Pipe size (Gas(mm))
0.0mm
Net Weight (kg)
137.0kg
Weight Empty (kg)
0.0kg
Weight Full (kg)
0.0kg
Pipe Size (Water(mm))
28mm
