system includes
Technical details
Classification
Brand
Samsung
Clasification
CAC
Category
360 Cassette
Accessories
Drain Pump
Included
Controller Type
Wireless
Efficiency
SEER
6.0
SCOP
4.0
Noise rating
Indoor Unit Sound (Power) (dB(A))
61dB(A)
Indoor Unit Sound (Pressure) (dB(A))
45dB(A)
Outdoor Unit Sound (Power) (dB(A))
70dB(A)
Outdoor Unit Sound (Pressure) (dB(A))
56dB(A)
Output power
Cooling kW
12.0kW
Heating kW
13.2kW
UK Cooling kW
0.0kW
UK Heating kW
0.0kW
Sensible UK Cooling kW
0.0kW
Power supply
Indoor Unit Power Source
Single Phase
Outdoor Unit Power Source
Three Phase
Indoor Unit Fuse Rating
3
Outdoor Unit Fuse Rating
30
Indoor Unit Max Running Current
1
Outdoor Unit Max Running Current
25
Product features
Refrigerant
R32
Colour
Black
BMS Ready
Yes
Drain Pump Lift
750
Weights & dimensions
Pipe size (Liquid (mm))
9.5mm
Pipe size (Gas(mm))
15.9mm
Max Pipe length (m)
50m
Max Pipe height (m)
30m
Net Weight (kg)
0.0kg
Refrigerant Precharge length (m)
30m
Additional Charge (g/m)
50g/m
Weight Empty (kg)
0.0kg
Weight Full (kg)
0.0kg
Indoor Unit Width (mm)
947mm
Indoor Unit Depth (mm)
947mm
Indoor Unit Height (mm)
365mm
Indoor Unit Weight (kg)
23.5kg
Outdoor Unit Width (mm)
940mm
Outdoor Unit Depth (mm)
330mm
Outdoor Unit Height (mm)
998mm
Outdoor Unit Weight (kg)
81.0kg
Fascia Panel Width (mm)
1050mm
Fascia Panel Depth (mm)
1050mm
Fascia Panel Height (mm)
66mm
