system includes
Technical details
Classification
Brand
Samsung
Clasification
EHS
Category
Monoblock
Accessories
Space Heating Pump Included
Yes
Magnetic Filter
Yes
Efficiency
SCOP
4.6
ERP Rating
B
Noise rating
Outdoor Unit Sound (Power) (dB(A))
56dB(A)
Outdoor Unit Sound (Pressure) (dB(A))
42dB(A)
Output power
Heating kW
8.0kW
Immersion heater Duty (kW)
3kW
Buffer Immersion Heater Duty (kW)
3kW
Maximum Flow Temperature (°c)
70°c
Maximum Hot Water Temperature (°c)
70°c
Power supply
Indoor Unit Power Source
Single Phase
Outdoor Unit Power Source
Three Phase
Indoor Unit Fuse Rating
3
Outdoor Unit Fuse Rating
17.7
Indoor Unit Max Running Current
1
Outdoor Unit Max Running Current
3.22
Product features
Refrigerant
R32
Re-Heat Time (min)
45min
Weights & dimensions
Water Volume (L)
250l
Weight Empty (kg)
81.0kg
Weight Full (kg)
331.0kg
Unvented Expansion Vessel Volume (L)
19l
Buffer Vessel (L)
50l
Pipe Size (Water(mm))
28mm
Indoor Unit Width (mm)
550mm
Indoor Unit Depth (mm)
600mm
Indoor Unit Height (mm)
2020mm
Indoor Unit Weight (kg)
81.0kg
Outdoor Unit Width (mm)
1270mm
Outdoor Unit Depth (mm)
530mm
Outdoor Unit Height (mm)
1018mm
Outdoor Unit Weight (kg)
126.0kg
